Electrofusion Equal Tee For Gas And Water
Injection moulded, embedded resistance wire by CNC machine,black HDPE100 material,working voltage 39,5V(dn450mm and above 60V), sizes range from dn20mm to dn560mm, pressure rating major for SDR11(dn355mm and above for SDR17).
Description
Main features:
Injection moulded, embedded resistance wire by CNC machine,black HDPE100 material,working voltage 39,5V(dn450mm and above 60V), sizes range from dn20mm to dn560mm, pressure rating major for SDR11(dn355mm and above for SDR17).
Suitable for:
Piping systems for water distribution (UNI EN 12201 - ISO 4427) up to PN16 bar; Piping systems for the distribution of fuel gas (UNI EN 1555 - ISO 4437).
Jointing method: Electrofusion.
|
Dn /MM |
N.W. KG/PC |
SIZE/MM |
|||||
|
SDR11 |
SDR17 |
A |
B |
L |
W |
DE |
|
|
20 |
0.050 |
/ |
36 |
41 |
86.7 |
77 |
31 |
|
25 |
0.075 |
/ |
39 |
41 |
96.5 |
84 |
36.7 |
|
32 |
0.095 |
/ |
40 |
46 |
106 |
96 |
43 |
|
40 |
0.160 |
/ |
43 |
50 |
122 |
112 |
53 |
|
50 |
0.240 |
/ |
51 |
55 |
142 |
130 |
63 |
|
63 |
0.400 |
/ |
55 |
62 |
168 |
152 |
79 |
|
75 |
0.600 |
/ |
64 |
70 |
188 |
173 |
94 |
|
90 |
0.900 |
/ |
65 |
83 |
204 |
206 |
110 |
|
110 |
1.550 |
/ |
72 |
83 |
237 |
232 |
136 |
|
125 |
2.100 |
/ |
80 |
87 |
262 |
250 |
152 |
|
140 |
2.750 |
/ |
82 |
90 |
278 |
277 |
169 |
|
160 |
4.050 |
/ |
96 |
100 |
322 |
315 |
190 |
|
180 |
4.500 |
/ |
98 |
102 |
340 |
340 |
222 |
|
200 |
6.800 |
/ |
96 |
112 |
362 |
381 |
240 |
|
225 |
8.600 |
/ |
107 |
122 |
397 |
412 |
310 |
|
250 |
11.550 |
/ |
112 |
134 |
427 |
465 |
306 |
|
280 |
16.450 |
/ |
129 |
141 |
480 |
438 |
330 |
|
315 |
22.600 |
/ |
125 |
157 |
524 |
540 |
370 |
|
355 |
/ |
26.100 |
179 |
180 |
705 |
616 |
402 |
|
400 |
/ |
43.300 |
200 |
175 |
800 |
682 |
457 |
|
450 |
/ |
58.700 |
200 |
190 |
857 |
751 |
520 |
|
500 |
/ |
81.300 |
200 |
195 |
912 |
814 |
580 |
|
560 |
/ |
108.900 |
205 |
209 |
990 |
899 |
650 |
